TRAN-203 SERIES, 20A 250V Three-Phase Transformer Analyser with Built-in Printer

Measurement Parameters
3-Phase Turns Ratio Measurement, Excitation Current, Phase Angle, Polarity, Ratio Error (%), Vector group detection, Magnetic Balance; 3-Phase Winding Resistance Measurement

Ratio Measurement Modes
CT Mode, PT Mode (Single-Phase and Three-Phase)

Measurement Method
ANSI/IEEE C57.12

Test Voltages
CT Mode: 1 V and 4 V ; PT Mode: 1, 4, 10, 40, 100 & 250 V

Ratio Range
0.8 – 50,000

Phase Angle Measurement
0-360 Degree, ±0.2 degree

Excitation Current
Up to 2 A

Excitation Current Accuracy
±0.1 mA

Test Voltage
50 V

Current output
From 0.001 A to 20 A DC (User-selectable)

Resistance Measurement
From 0.1 μΩ to 100,000 Ω

Accuracy
Current Range

1 mA – 10 mA

Resolution
5 digits

Demagnetisation
Yes

Power Supply
100-240 V, 47/63 Hz,

Battery
14.4 V 6.9 Ah battery (Models: TRAN-203B, TRAN-203B BLUE)

Internal Memory
Yes

Printer
2.28-inch Built-in Printer

Communication
USB 2.0/1.1 Standard-A, USB 2.0/1.1 Standard-B, Bluetooth(Models: TRAN- 203BLUE & TRAN- 203B BLUE)

PC Software
Data Management Platform Software

Display
7-inch colour touch display

Dimensions
(16.9 × 12.9 × 9.3)” (429 x 328 x 236) mm

Weight
9.5 kg

Temperature
Working: -10 °C to +60 °C; Storage: -30 °C to +70 °C

Humidity
95% RH Non-condensing

Protection Class
IP67 (case lid closed)

Included in the package
