TURA-03B is designed using advanced engineering technology to measure the turns ratio of single-phase and three-phase transformers. TURA-03B has fast, easy and accurate TTR measurement features for current, voltage and power transformers using its user-friendly software. By using ANSI/IEEE C57.12.90 measurement method TURA-03B can produce precise results. TURA-03B is one of the most accurate devices with its wide range (0.8 to 50,000) ratio measurement capability and high precision (0.08 %).
Besides the ratio measurement, TURA-03B can also measure excitation current, phase angle, polarity and ratio error. Even though TURA-03B has a three-phase cable configuration, users can make single-phase transformer tests as well. TURA-03B can detect vector groups automatically. TURA-03B has a wide operation range from high excitation value current transformer to high powered power transformer at substations with the 1V, 4V, 10V, 40V, 100V and 250V AC test voltage generation capability.
A 7-inch colour touch display allows TURA-03B to show all measurement results on a single screen. USB, Bluetooth (Option) and Flash Memory features allow TURA-03B to control, record and store measurement results (up to 100 Test Records). With the HighTest Data Management Platform (DMP Software), users can control TURA-03B and analyse measurement results. Operators can easily print the measurement results with the 2.28-inch built-in Printer of TURA-03B. Multi-language capability and user-friendly operation menu make it easy to control TURA-03B, even by less trained staff.
TURA-03B can control the tap changer (raise and lower) via its tap changer outputs. TURA-03B is a light, compact and rugged device with the protection of IP67 (case closed).
In addition to ratio tests, TURA-03B can be used to perform the Magnetic Balance Test as well.
